$7,184.62
Harken 200mm Aluminum Teardrop Block—
$7,184.62
The Story
Product Description
Harken 200mm Aluminum Teardrop Block
Sideplates are constructed of hardcoat-anodized 6061-T6 aluminum for strength and corrosion resistance. The ultralight composite bearing system (ULC) rides on a heat-treated stainless steel inner race to handle extremely high loads.
Specifications:
- Sheave Ø: 200mm
- Weight: 14.2 lbs. (6.441 kg)
- Maximum Line Ø: 1 1/8 in. (28mm)
- Maximum Working Load: 50715 lbs. (23000 kg)
- Breaking Load: 101430 lbs. (46000 kg)
Description
Product Description
Harken 200mm Aluminum Teardrop Block
Sideplates are constructed of hardcoat-anodized 6061-T6 aluminum for strength and corrosion resistance. The ultralight composite bearing system (ULC) rides on a heat-treated stainless steel inner race to handle extremely high loads.
Specifications:
- Sheave Ø: 200mm
- Weight: 14.2 lbs. (6.441 kg)
- Maximum Line Ø: 1 1/8 in. (28mm)
- Maximum Working Load: 50715 lbs. (23000 kg)
- Breaking Load: 101430 lbs. (46000 kg)
